1200W Ultrasonic Cleaning Machine Manually Adjustable Safe Reliable Easy Install

1200W Ultrasonic Cleaning Machine Manually Adjustable Safe Reliable Easy Install

1200W standard single-tank ultrasonic cleaning machine

• One: This machine model: CCS-1024BZ
• Second: main use and scope of application: for basic cleaning of various products
• Three: inner slot size: 600 * 400 * 400MM
• Four: Production: Manually adjustable.
• Five: The main advantages of the standard single-tank ultrasonic cleaning machine:

1: The appearance of the device is beautiful. It is supported by four brake universal wheels, which can be pushed and fixed, and the operation is very flexible;
2: Appearance and liner materials are made of high quality SUS304/316L stainless steel material and durable;
3: Easy to install, easy to operate, safe and reliable;
4: Using high-quality transducers and a unique ultrasonic generator, the ultrasonic power is strong;
5: Adopt Japanese high-Q vibrator chip to ensure strong vibration, long service life and late decay of ultrasonic power.
6: Ultrasonic frequency can be selected: 28KHZ, 40KHZ, 68KHZ, 80KHZ, 120KHZ, 135KHZ, 180KHZ, 200KHZ, etc.;
7: Designed with automatic temperature control heating device, the temperature in the temperature control range is usually ~100 °C;
8: The ultrasonic generator and the tank body can be made in one piece or in a split type.

Six: Working conditions:

• Ambient temperature: normal temperature ~ -30 ° C
• Humidity: ≤80%
• Plant grade: It is recommended to use standard factory buildings
• good ventilate
• Meet ROHS standards

Seven: Security level:
Meet mechanical safety production standards

Eight: The working process of this washing machine is introduced:
Standard ultrasonic cleaners can clean a wide range of products.
Check whether the machine is energized, add appropriate amount of liquid after power-on (some need cleaning agent), adjust the heating temperature to the temperature to be cleaned, generally about 60 degrees, put the workpiece into the cleaning basket and then put it into the tank. The ultrasonic generator is turned on and the ultrasonic wave starts to work. A cleaning process can be completed in about 5-10 minutes. Lift the workpiece, if necessary, some need to be baked, and some do not need to go to the next process to complete a cleaning process

.
Nine: Randomly equipped with an ultrasonic generator
Is the frequency of the ultrasonic transducer, generally used in ultrasonic equipment, the ultrasonic frequency is 28KHz, 40KHz;
I believe that the use of the surface will gradually expand. A relatively complete ultrasonic generator should also have a feedback link, mainly providing feedback signals in two aspects:

The first is to provide the output power signal, we know when the power supply (voltage) of the ultrasonic generator changes. The output power of the ultrasonic generator will also change. At this time, it is reflected in the ultrasonic transducer that the mechanical vibration is suddenly large and small, resulting in unstable cleaning effect. Therefore, it is necessary to stabilize the output power, and the power amplifier is adjusted correspondingly by the power feedback signal, so that the power amplification is stable.
The second is to provide a frequency tracking signal. When the ultrasonic transducer works at the resonance frequency point, its efficiency is the highest, and the work is the most stable. The resonance frequency of the ultrasonic transducer will change due to assembly reasons and work aging. Of course, the frequency of this change is only drift, and the change is not very The large, frequency tracking signal can control the signal ultrasonic generator so that the frequency of the signal ultrasonic generator tracks the resonant frequency point of the ultrasonic transducer within a certain range. Let the ultrasonic generator work at its best.
