^{(1) Be sure to pay attention to first open the blower and then open the heater. Turn off the heater first, then turn off the blower.
(2) When the thickness of the glass plate changes, the height of the wind knife must be adjusted first, otherwise it will cause damage.
(3) Before stopping the transmission of the motor, be sure to lower the speed regulator to zero.
(4) There is an emergency stop button on the console, which can be used in case of emergency.
(5) The glass must be placed within the limit of the feed section.
(6) When adding tap water to the washing water tank, the water level should not exceed 250MM. When the water level is lower than 200MM, water should be added in time.}

^{It is very important to carry out daily maintenance and maintenance of the machine. Usually, you should observe the moving parts of the machine, the waterway system, the airway system, and the electrical system. If there is an emergency, stop the vehicle immediately.}

^{(1) Bearing and lubrication
Lubricate each lubrication point in time.}

^{(2) Maintenance of the waterway system
The water used in the cleaning section is used for recycling. The water in the water tank should be replaced every day to ensure the clean water is cleaned, and the water tank and filter device are cleaned once a month. The water spray can be monitored through the observation hole on the cleaning section cover. If there is any blockage, stop the pump to open the cover, remove the water spray nozzle, and clean the installation after cleaning.}

^{(3) Maintenance of the shunt system
Check the operation of the blower regularly, stop it immediately when there is abnormal sound, and report it to the maintenance department for inspection. Clean the filter grille of the air inlet every two months, and keep the blower room clean during normal times to prevent dust from being sucked into the air path and contaminating the glass.}

^{(4) Waterway system
The waterway system is shown in Figure 3. It consists of two sets of water tanks and four sets of circulating water systems. The detergent tank should use a neutral glass cleaner with a pH of 7 and the last glass rinse should use deionized water. The quality of the water directly affects the surface cleanliness of the rear glass. The temperature of the washing liquid is generally controlled at 30 to 60 degrees (the water temperature heating control device is provided by the user).}

^{(5) Wind path system
As shown in Fig. 4, the compressed air from the blower is separately sent to the upper and lower cold air knives and the distance between the upper and lower hot air knives and the glass plane can be adjusted. When changing the thickness of the glass, it is necessary to adjust this. gap.}

^{(6) Installation and adjustment
1 The site conditions should have 380V AC power supply, industrial tap water source and drainage ditch.
2 As shown in Figure 7, correctly place the feed section rack, the cleaning section rack, the drying section rack, the discharge section rack, the control cabinet, and the ventilation cabinet.}
