^{Non-standard automation equipment is customized according to customer requirements. It is characterized by non-standard and customization. Chengchengshan Automation can customize the automation equipment required by various customers according to the requirements of customers. For example, we need 5-6 people to educe a factory now. We think its process and products are standardized, and the following are produced according to the production process. Instead of artificial self-coordinating equipment, as follows:}

^{First, the equipment name: automatic edge grinding machine
Second, the equipment model: CCS-3000XB
Third, the device model description:
HS Dongguan Chengchengshan Automation Equipment Co., Ltd.
3 ━ There are 3 function stations in the whole machine.
XB━ equipment is trimming}

^{Fourth, the equipment overview:
1, equipment overview}

^{The company is a professional machinery manufacturing enterprise with more than ten years of surface treatment and high-tech research and development, design, manufacture and sales. It is also a manufacturer with relatively strong scale in the same industry.
This program is a three-station automatic edger designed according to your company's technical requirements and product features, which can meet the requirements of removing burrs and grinding the inner circle of the workpiece.
Design idea: three-dimensional pneumatic handling, clamping workpiece, pneumatic chuck clamping workpiece, rotating spindle speed adjustable, while carrying three workpieces, three grinding heads at the same time, the second and third grinding heads have compensation function, when After the grinding wheel is worn, the grinding wheel can be automatically compensated.}

^{2. Scheme design basis and main technical parameters}

• The main technical parameters:
• ^{Main parameters: about L1200*950*H1400}
• ^{Rotating motor: 550W, 3 sets}
• ^{Grinding head motor: 400W, 3 sets}

^{Fifth, the process
This machine is divided into automatic mode and manual mode. The automatic mode is generally used in the production process, while the manual mode is generally used.
For equipment commissioning, maintenance, etc.}

^{Manual operation:
1) Open the main valve of the air supply, close the power switch, and start the dust removal fan at the same time.
2) Turn the operation mode selection knob to manual mode to debug or repair the device.
●The spindle speed and the grinding head speed can be adjusted according to the grinding effect.}

^{Automatic operation:
1) Open the main valve of the air supply, close the power switch, and start the dust removal fan at the same time.
2) According to the characteristics of the processed product, adjust the position of the grinding head, the workpiece, the rotation speed of the motor, switch the operation mode selection knob to the automatic mode, press the “Start” button, and the machine enters the automatic state.
3) Work when the workpiece is sensed on the rack.
4) The workpiece is automatically dropped into the receiving basket.}
