Stainless steel kettle cup hanging chain dewaxing ultrasonic cleaning machine

Stainless steel kettle cup hanging chain dewaxing ultrasonic cleaning machine
One: The function and cleanliness requirements of the equipment:
1. Cleanliness requirements: The workpiece is cleaned on-line and cannot be discolored or corroded by itself. The surface of the workpiece after cleaning shall not be contaminated with oil, dust and other contaminants.
2. Surface treatment requirements: uniform, no stains, stains;
3. Drying requirements: After the cleaning, the surface of the workpiece is dry and free of water.
Two: the basic principles and characteristics of ultrasound
The 40KHZ super-audio electrical signal generated by the ultrasonic generator is converted into mechanical oscillation of the same frequency by the piezoelectric effect of the transducer and radiated in the cleaning liquid in the form of super-audio mechanical waves. Due to the alternating action of the positive pressure zone and the negative pressure zone of the super-audio mechanical wave propagation, numerous tiny bubbles of more than 1000 atmospheres are generated and blasted at any time to form a fine local high-pressure bombardment on the surface of the cleaning object, so that the dirt on the surface of the object and the gap is rapid. Peeling, this is the "cavitation effect" unique to ultrasonic cleaning.
Three: 1. Cleaning tank:
(1) Effective inner groove size: 600 × 500 × 500 (L × W × H mm)
(2) The tank body is made of SUS304 2.0mm stainless steel sheet.
(3) An overflow device is provided, and the outflowing cleaning liquid enters the liquid storage tank, and is filtered again after being filtered by the ring filtration system;
(4) equipped with water valve, drain valve, sewage into the total drain;
(5) Heating: tubular heating device, heating power 9KW. Heating temperature room temperature -80 °C adjustable (to prevent heat loss, all heating parts of the outer groove are covered with insulation cotton, insulation cotton thickness 10mm), temperature control tolerance ± 3 ° C (the same below); single display thermostat with Japan "Omron" brand.
(6) Cleaning medium: municipal water + cleaning agent
2. Ultrasound system:
(1) Ultrasonic frequency: 40KHZ;
(2) Ultrasonic power: 1800W
(3) Ultrasonic vibrators: 36 pieces, 50W/only, immersed ultrasonic vibration plate, installed at the bottom of the tank, the core components of the vibrator adopt Japanese “Bundo” brand chips;
3. Storage tank:
(1) Inner groove size: 400 × 400 × 400 (L × W × Hmm)
(2) The tank body is made of SUS304 2.0mm stainless steel sheet, and 10mm thick insulation cotton is attached;
(3) Set the low level protection alarm control system.
(4) Heating method: stainless steel tube heating
Heating power: 5KW
4. Filter circulation system:
(1) Stainless steel filter pump power: 370W, domestic “Southern” brand, flow: 30L/min, continuous filtration cycle;
(2) a set of stainless steel filters;
(3) Filtration accuracy: 10μ;
