PCB Alkaline Etching Solution Copper Recovery Equipment

Recycling and Copper Recovery Equipment of Alkaline Etching Solution for Circuit Board
The alkaline etching liquid recycling system is a clean production equipment upgraded by PCB enterprise's etching process technology transformation. It can make the copper-containing wastewater meet the zero discharge standard and control the diffusion and transfer of pollution sources. The cost of production is greatly reduced and the efficiency is greatly improved. The output copper content is over 99.95%.
At present, the company's copper etchant recycling equipment has formed batch production, and has successfully been industrialized in several PCB plants in Guangdong for more than four years. The whole closed-circuit working cycle of the equipment produces no waste liquor or gas. The regenerative etching liquor produced has better application and stability in production than the newly purchased sub-liquor, reflecting the advanced technology, maturity and reliability of the system.

1. Overview
The system is a set of high-tech, environmental protection equipment, is designed for the treatment of alkaline etching wastewater and a fully enclosed system, without any waste water, waste discharge. The system can not only regenerate the waste etching solution and return it to the etching line for use, but also provide stable etching effect for the etching line, and create enormous economic benefits and environmental benefits. After the system is connected with the etcher, it can automatically circulate and recycle the etching solution and ammonia washing water.
2. Main functions and characteristics
The waste etching solution is regenerated, and the regenerated etching solution can be recycled.
(2) Copper ions in waste etching solution and ammonia washing water are recovered and reduced to high purity electrolytic copper;
The equipment is easy to operate and maintain, does not affect production in the process of installation and debugging, and can be put into use after installation and debugging.
3. Principles
In the process of circuit board etching, the concentration of copper ion in etching solution will gradually increase and the etching effect will be reduced. In order to achieve the best etching effect, it is necessary to keep the copper ion (Cu2+), chloride ion (Cl-) and PH values in etching solution within a reasonable and stable range, and to continue the above-mentioned composition in etching solution. The optimum concentration of fraction requires the continuous addition of molecule liquor to replace the "waste etching liquor" which has lost etching ability. The system can regenerate the waste etching liquid which was originally needed to be discharged into a new sub-liquid, i.e. regenerated etching liquid. It only needs to add a very small amount of supplement to supplement the part lost in the etching process and can be recycled. At the same time, the ammonia washing water is recycled and recycled.

4. Product Model
Through the investigation and repeated demonstration of PCB industry, our company has designed the following six alkaline standard series of machines with different specifications. In addition, our company can also carry out non-standard design according to the special requirements of customers.
Model: HS-200 (20 tons of waste liquid per month)
Model: HS-300 (30 tons of waste liquid per month)
Model: HS-450 (45 tons of waste liquid per month)
Model: HS-600 (60 tons of waste liquid disposal per month)
Model: HS-900 (handling 90 tons of waste liquid per month)
Model: HS-1000 (100 tons of waste liquid disposal per month)
